Auto Assembly

Extensions and Python Add-ons Visual Components Add-on Samples
1

Hi,

Auto Assembly add-on creates product types and assembly type for process modeling using existing components, nodes or features as a source. Add-on requires VC 4.4 or newer as on 4.4 there were new APIs introduced to access assembly types. Add-on package includes PDF instructions on how to use the add-on. There are few demo videos of different use cases.

Add-on
AutoAssembly_06_06_2023.zip (316.0 KB)

Quick demo video

Quick demo 2 - CAD imported features
(Note: use shift to drag-drop features to keep their world position the same)

-k

9 Likes
2

Add-on has been updated so that it works also in 4.7. As there were some changes to product filters in 4.7 the old version of this add-on didn’t work anymore. Now the code has been updated, see the attachment in original post.

-k
